Exhibition model of a turbocharger. Made from real auto part. The double coloring and wide cutout make it easy to see and examine the core of the turbocharger and all the small components inside. And also understand the principle of operation of this unit in the car. // The real product may differ from what is shown in the photo - the Exhibition model can be made from a turbocharger of any model.
The TP-TACT device is intended for testing the operation and programming of the range of work of electronic turbocharger controllers.
With TP-TACT it is possible to perform the following tests:
test of electronic controllers of turbochargers with wastegate
test of electronic actuators of turbochargers with variable geometry (VTG, VNT).
test of dc motors from turbocharger actuators,
test of wastegate positio...
TURBO-PROG supports two types of turbo actuators:
Hella,
Siemens.
For Hella actuators TURBO-PROG allows the user to :
read actuator parameters,
store actuator parameters in device internal memory,
program actuator parameters,
copy actuator parameters.
The term 'actuator parameters' means the following information:
actuator type,
gearbox number of compatible gearbox,
version of actuator firmware,
range of operat...
QTZ0008Тестер для диагностики эл. клапана турбокомпрессора
Кроссы
MH VNTTPROV4
MH VNTTPROv407(USB)
Применяется для
VNTT-PRO tester is designed to perform diagnosis of actuators (electric valves, DC motors) of VNT (Variable Nozzle Turbine) turbochargers. These actuators changes position of turbocharger vanes in the same way as in turbochargers where turbine geometry was changed using vacuum. Apart from testing electronic turbocharger units VNTT-PRO tester can be used to check variable geometry position sensors. These are found ...
QUZ0010Стенд для настройки и проверки турбокомпрессоров
Кроссы
KR QUZ0010
Применяется для
Компактный дизайн
Встроенная подача воздуха
Измеряет цифровые и аналоговые вестгейты всех моделей автомобилей.
Предусмотрены калибровочные тестовые пластины для простой проверки точности машины.
Быстросъемный монтажный фланец в комплекте с четырьмя переходниками
Простое и понятное программное обеспечение с сенсорным интерфейсом.
Поддерживает протоколы автоматической связи PWM, FDCan, Can2.0, Linbust, J1939.
Напряж...
QZZ0004Стенд для балансировки картриджа турбокомпрессора
Кроссы
CIM CMT48VSRTwin
MH QZZ0004
Применяется для
CMT-48 TWIN core assembly balancing machine // Technical data of CMT-48 VSR unit:
Balancing speed up to 280.000rpm
Min. achievable residual imbalance 0,005gmm
Core assembly weight up to 10kg
Oil pressure in lubrication system up to 4 bar
Amount of air per measurement run 300l
Air compressor pressure 8 bar
General technical data of the both units:
Machine weight 450kg
Dimension 1450x1050x1400
Power supply 230v/50Hz...
Advantages of dynamic calibration of VNT turbochargers:
Dynamic calibration (the rotor is spinning) of variable geometry according to airflow— calibration of minimum, medium and maximum flow
Compressor section performance test
Turbocharger oil leakage test
REA of Hella, Siemens testing and reprogramming
Pneumatic and vacuum actuator test
Position sensor test
Turbocharger boost pressure ratio test. Real life spi...
The world’s first bench top VNT calibrator, with a compact design that combines efficiency and accuracy at a competitive price.
The BenchFlow 2000 is packed full of all the essential features required by the turbo re-manufacturing industry,
These include:
9" TFT LCD Widescreen with Resistive Touch Screen.
Automatic Correction for Temperature, Humidity and Atmospheric Pressure.
On-board Actuator Drivers for bot...
